Assy Main Frame assembly for Crafter M6 Crafter3D

M6_A_1000 - Assy Main Frame

Versione 2 (25-06-2025)

icon Crafter3D 3d printed items Parti stampate in 3D:
18
icon Crafter3D Filament Filamento totale richiesto:
420.78 grammi
icon Crafter3D 3d printing time Tempo totale di stampa:
14.66 ore
icon Crafter3D subassembly Sotto-assiemi
1
icon Crafter3D 3d commercial items Parti commerciali:
18
icon Crafter3D screws Viti:
38
icon Crafter3D electrical items Parti elettriche
0
<< Back
icon Crafter3D 3d printed items
Numero di Parte Nome Immagine Quantità Colore Riempimento(%) Peso(g) Tempo di Stampa(h) Materiale di Stampa Versione Ultimo Aggiornamento
M6_P_0073 Front Tower Right Core XY Front Tower Right Core XY 1 Blue 20 % 106.1 g 3.05 hours PETG 6 2025-06-24
M6_P_0116 Top Holder Position Core XY Top Holder Position Core XY 2 White 10 % 6.74 g 0.33 hours PETG 3 2024-11-18
M6_P_0117 Top Holder Handle Position Core XY Top Holder Handle Position Core XY 2 White 10 % 6.81 g 0.35 hours PETG 2 2024-09-11
M6_P_0072 Front Tower Left Core XY Front Tower Left Core XY 1 Blue 20 % 106.1 g 3.05 hours PETG 6 2025-06-24
M6_P_0009 Rear Tower Left Core XY Rear Tower Left Core XY 1 Blue 20 % 86.11 g 2.5 hours PETG 10 2025-06-24
M6_P_0003 Clip Acrylic Panel Clip Acrylic Panel 6 Black 100 % 0.97 g 0.22 hours PETG 2 2024-12-21
M6_P_0074 Rear Tower Right Core XY Rear Tower Right Core XY 1 Blue 20 % 86.11 g 2.5 hours PETG 5 2025-06-24
M6_P_0008 Cable Clip Cable Clip 4 Black 100 % 0.86 g 0.22 hours PETG 2 2024-12-21
icon Crafter3D 3d commercial items
Numero di Parte Nome Immagine Quantità Versione Ultimo Aggiornamento
C_0114 Aluminum Profile Structure Front Aluminum Profile Structure Front 2 3 2025-06-24
C_0115 Aluminum Profile Structure Rear Left Aluminum Profile Structure Rear Left 1 3 2025-06-24
C_0116 Aluminum Profile Structure Rear Right Aluminum Profile Structure Rear Right 1 3 2025-06-24
C_0113 Aluminum Profile Structure Middle Aluminum Profile Structure Middle 3 3 2025-06-24
C_0117 Aluminum Profile Rear Aluminum Profile Rear 2 3 2025-06-24
C_0148 Wiring Cover Acrylic Panel Black Wiring Cover Acrylic Panel Black 1 1 2024-12-09
C_0090 M3x5x4 threaded heat set insert M3x5x4 threaded heat set insert 4 6 2024-10-03
icon Crafter3D screws
Numero di Parte Nome Immagine Quantità Testa della Vite Metrico Lunghezza Versione Ultimo Aggiornamento
M3x10 Hex M3 x 10mm DIN912 Hex M3 x 10mm DIN912 Hex 4 Hex M3 10 mm 1 2024-09-09
M5x20 Button M5 x 20mm ISO7380 Button M5 x 20mm ISO7380 Button 2 Hex M5 20 mm 1 2024-10-03
M5x25 Hex M5 x 25mm DIN912 Hex M5 x 25mm DIN912 Hex 28 Hex M5 25 mm 1 2024-09-02
icon Crafter3D electrical items
Numero di Parte Nome Immagine Quantità Inizio connettore Fine connettore Cavo Lunghezza Versione Ultimo Aggiornamento
Nessuna vite in questo assieme
icon Crafter3D sub-assembly
